2.Product feature and application
50Hz date
Model Nominal Cap.(TR) Power input(kw) COP(W/W)
SZ100 8 6.84 3.15
SZ115 9.5 8.49 3.16
SZ120 10 8.98 3.18
SZ148 12 10.99 3.19
SZ160 13 11.77 3.28
SZ161 13 11.83 3.21
SZ175 14 12.67 3.17
SZ185 15 13.62 3.16
SZ240 20 18.60 3.18
3.Production details
Diameter [mm]:254mm
Net weight：76.84 kg
Oil charge [L]: 3.25 L
Oil reference:160SZ
Fitting standard: ODF
Factory HP [bar]：33 bar
Motor protection：Internal overload protector
Capacity control：Fixed speed
Connection type： Brazed
5.,Delivery and Packing
1)Delivery:
Here we guarantee on time delivery and if necessary,
we will provide you the best logistics solution for the goods to reach at your location on time.
2)Packing:
Every products will be in carefully inspection for many times before Packing.
Depending on the size and contents of your goods,
we generally use different size of wooden box of package to secure goods.
